(CWC): Introducing Avalue’s Fanless Rugged Computing Solutions: ACS10-TGU and EPC-EHL-8COM
Introducing Avalue’s Fanless Rugged Computing Solutions: ACS10-TGU and EPC-EHL-8COM
Avalue, a leading provider of innovative computing solutions, presents two exceptional products in their lineup: ACS10-TGU and EPC-EHL-8COM. These compact and highly versatile systems offer a wide range of features and capabilities, making them ideal for various IoT applications. Let’s take a closer look at these remarkable offerings.
Avalue recently released fast-to-implement ACS10-TGU box PC, powered by Intel® 11th-Gen Tiger Lake UP3, which is specifically designed for IoT-related operations. The ACS10-TGU also stands out with its compact design and ease of setup. Equipped with highly expandable I/O interfaces and a flexible storage design, this system provides seamless integration and exceptional performance. Its support for high-resolution graphics ensures stunning visual output.
One of the key strengths of the ACS10-TGU is its stable high-speed connectivity, enabling real-time feedback and analysis for IoT applications. Its comprehensive architecture not only reduces development costs but also ensures a short implementation time. The system boasts an operating temperature of up to 50℃ and has successfully passed a rigorous 50G shock test. With support for up to 32GB DDR4 3200MHz memory, an M.2 Key B/E expansion slot, and a diverse range of I/O ports (including 2 x COM, 6 x USB ports, 2 x DP++, and 2 x Ethernet ports), the ACS10-TGU is a versatile solution.
With its compact form factor and rapid implementation capability, the ACS10-TGU finds its perfect fit in various applications such as retail kiosks, digital signage, industrial automation, smart city, and video surveillance.
ACS10-TGU’s Key Features | 11th Gen Intel® Tiger Lake Fanless Compact System
- 11th Gen Intel® Core™ i5/i3 Tiger Lake-UP3 Processor
- Intel® Iris® Xe/ UHD Graphics Engine
- 1-260-pin DDR4 3200MHz SO-DIMM, Supports Up to 32GB
- 2-Gigabit Ethernet, 1 x 2.5GbE, 1 x 1GbE
- 2-COM Port (RS-232/422/485 & RS-232)
- 2-Audio Jack (Line-Out & Mic-In)
- 2-Storage (M.2 Key-M NVMe & M.2 Key-B SATA)
- 2-Expansion Slot (M.2 Key-E, Key-B)
- 6-USB Port (3-USB 3.2 & 3-USB 2.0)
- CE, FCC Class A, UKCA
Product Details / DatasheetFor the another highlighted fanless system, the EPC-EHL-8COM from Avalue is a rugged and fully integrated compact fanless computing system. It offers an ultra-thin platform, making it an ideal choice for demanding IoT applications. The system’s easy setup, highly expandable I/O interfaces, and high-speed connectivity designs further enhance its appeal.
At its core, the EPC-EHL-8COM features an Intel® Elkhart Lake Processor x6413E with Intel® UHD Graphics, ensuring powerful performance and high-quality graphics output. The memory socket supports up to 32GB DDR4 3200, enabling smooth multitasking and efficient data processing. Notably, this product operates in fanless conditions, ensuring silent operation and enhanced reliability. Its outstanding operating temperature range of -40°C to 70°C guarantees optimal performance in challenging environments.
The EPC-EHL-8COM excels in its I/O capabilities, accommodating up to 8COM ports, offering extensive connectivity options for various devices. This makes it a perfect choice for applications requiring multiple serial interfaces.
EPC-EHL-8COM’s Key Features | Intel® Elkhart Lake Fanless Compact System
- Intel® Elkhart Lake Processor x6413E
- Intel® UHD Graphics, Max. Up to 32EU
- Memory Socket, Max. Up to 32GB DDR4 3200
- Rich I/O, 4-USB, 1-HDMI, 1-DP, 2-LAN, 8-RS232, 1-Mic-in, 1-Line-out
- 2-M.2, Key-E/B for Wi-Fi, LTE, SSD, I/O module
- Fanless Operating Temp, -40 ~ 70°C
- Wide Range DC Power Input, +9V~36V
- Default dTPM 2.0, Wall Mount Kit
Product Details / Datasheet
Despite a slowdown in the global economy, there is continuous investment in inelastic demand, such as IoT, unmanned stores, 5G and smart manufacturing. Avalue’s ACS10-TGU and EPC-EHL-8COM exemplify the company’s commitment to delivering innovative and reliable computing solutions. With their compact designs, expandable I/O interfaces, high-speed connectivity, and exceptional performance, these products are ideally suited for IoT applications. Whether it’s retail kiosks, digital signage, smart office access systems, or video surveillance, Avalue’s compact computing solutions provide the flexibility and reliability required in today’s evolving technological landscape.
