(CWC): COB LED Wall – Revolutionizing Visual Displays
In recent years, the advancement of technology has paved the way for innovative solutions in the field of visual displays. One such groundbreaking development is the COB LED Wall (“Chip on broad”). With its exceptional features and numerous advantages, the COB LED Wall has become a popular choice for various applications, ranging from shopping malls and universities to outdoor public areas and hospitals.
What is COB LED Wall?
COB, or Chip-on-Board, LED Wall refers to a display technology that utilizes a densely packed array of LED chips mounted directly onto a substrate. This arrangement eliminates the need for individual LED packages, resulting in a seamless and uniform display surface. The COB LED Wall is designed to deliver outstanding visual quality and performance in a wide range of settings.
What is the difference between traditional LEDs?
The COB LED Wall is a revolutionary technology that addresses the limitations of traditional LED displays. In traditional LED displays, multiple colors (Red, Green, and Blue) are packaged into a single Surface Mounted Devices (SMD) LED component. These components are then soldered onto a PCB in an array to form an LED wall module.
However, as pixel pitch decreases below P1.8, the number of SMD LED components increases significantly. This leads to issues such as fragile soldering points that can break easily and limited heat dissipation due to small contact areas.
COB (Chip-on-Board) technology is the solution to these problems. With COB LED Wall Display, LED chips are directly bonded onto the PCB using high precision manufacturing techniques. An epoxy layer is added to protect the bonding, eliminating several steps involved in SMD technology. This streamlined process improves yield rates and addresses the limitations of traditional LED displays.
Advantages
As COB has continuous epoxy layer, which can provide high protection from dust, water, and impact force, while there are only has 4 soldering points between each individual SMD package and PCB
Flip-chip COB will save the step of wire bonding, which results in a more higher effective luminous area under the same chip size, 20% energy saving & reduce temperature rise. As there is no bonding wire over light path block the light.
Flip-clip COB will have 40% larger luminous chip size, which can contribute to higher peak brightness up to 2000cd/m. Higher black occupancy contributes to 4 times higher contrast.
Main Features
- High Contrast & Brightness:
ZERO light blocking ensures superb sharpness and contrast
- Wide Viewing Angle:
Nearly 180° viewing angle with dazzling brightness and colour contrast
- Shock Resistant & Waterproof:
COB Epoxy Layer offers solid protection on the once-fragile display
- Eye-friendly Displays:
Low blue light emission prevents eyes strain even under long exposure to the display
Where can we apply COB LED Wall?
- Shopping Malls:
COB LED Walls can be used for captivating advertisements, promotional displays, and brand showcases, enhancing the overall shopping experience.
- Universities:
In educational institutions, COB LED Walls can be utilized as informational displays, interactive boards, or creative platforms for presentations and events.
- Outdoor Public Areas:
COB LED Walls are an ideal choice for outdoor advertising, digital billboards, and entertainment venues, captivating audiences with dynamic and visually striking content.
- Hospitals:
COB LED Walls can be employed for informative signage and patient entertainment, providing a visually engaging and positive environment for patients, visitors, and healthcare professionals.
Our Products
COB LED Wall | COB LED Stand |
 |  |
P0.7 / 0.9 / 1.2 / 1.5 / 1.9 / 2.5 | P0.9 / 1.2 / 1.5 / 1.8 |
– High contrast & brightness – 180° viewing angle – Shok resistant – Vandalproof & waterproof – Eye-friendly display | – High protection – IP54, waterproof & dustproof – Comfortable viewing experience – Fanless heat dissipation – Module seamless splicing |
If you are interested in COB LED Wall, please contact us immediately!
Our team is ready to offer you the most suitable products and solutions tailored to your business requirements.
