品牌
中央處理器
晶片組
USB/SATA/COM/LAN 電腦接口
嵌入式電腦系統
型號
品牌
中央處理器
晶片組
USB/SATA/COM/LAN 電腦接口
顯示
溫度
擴充插槽
尺寸
規格書 / 查詢
MERA-2100 Series
Arestech
Intel® Celeron® Processor J1900
N/A
5/3/2/2
HDMI/VGA/DVI/DP
-40°C ~ 70°C
1x Full-size Mini-PCIe Socket (mux with mSATA) and 1 x Full-size Mini-PCIe
168mm x 47mm x 135mm
MEVA-2012E/P
Arestech
Intel® Celeron® Processor J1900
N/A
5/2/6/2
HDMI/VGA/DP/DVI-I
-40°C ~ 70°C
1x Full-size Mini-PCIe Socket, 1x Full-size Mini-PCIe, 2x SIM Holder, 4x Antenna Hole, 2x PCIe X4 Slots, 2x PIC Slots
127mm x 168mm x 216 mm
MERA-2000 Series
Arestech
Intel® Celeron® Processor J1900
N/A
5/2/2/2
HDMI/VGA/DVI/DP
-40°C ~ 70°C
1x Full-size Mini-PCIe Socket (mux with mSATA) and 1 x Full-size Mini-PCIe
168mm x 47mm x 135mm
CB-2200/2250
Arestech
Intel® Alder Lake-N Processor N97 / Intel® Alder Lake Core™ i3-N305
SoC
5/1/2/2
DP
-40°C ~ 70°C
1 x Full-Size Mini-PCIe, 1 x M.2 B-Key, 2 x SIM Holders
168 x 135 x 47mm
FLEX-BX210-Q470
IEI
10/11 th Gen Intel® Core™ CPU 35/65W
Q470/Q470E
6/4/2/3
HDMI/DP
-10°C ~ 50°C
1 x M.2 B-Key 3042/52 socket (with SIM card slot, supporting 5G/LTE; supports PCIe 3.0 x1 & USB 3.2 Gen 1) 1 x M.2 M-Key 2280 socket (supports PCle 3.0 x4) 1 x M.2 A-Key 2230 (supports PCIe 3.0 x1 & USB 2.0)
357mm x 230mm x 88mm
HTB-150-N6210
IEI
Intel® Celeron® Processor N6210
N/A
4/0/1/2
HDMI
0°C – 40°C
1 x M.2 2230 A key slot, 1 x M.2 2280 M key slot
137 mm x 102.8 mm x 36 mm
mBOX603
Axiomtek
13th/12th Gen Intel® Core™ i9/i7/i5/i3
R680E
4/2/2/2
HDMI/DisplayPort++
0°C ~ 40°C
2 x Full-size PCIe, 1 x M.2 Key E 2230, 1 x M.2 Key B 3052/3042
310mm x 332mm x 145mm
SB-5000
Arestech
13th/12th Gen Intel® Core™/Pentium®/Celeron® 35W LGA 1700
Intel® R680E
9/2/6/6
HDMI/VGA/DP
-40°C ~ 70°C
1x Full-Size Mini-PCIe, 1 x M.2 B-Key 2242/3042/3052, 1 x M.2 E-Key 2230, 2 x Mini-SIM Holder
240mm x 200mm x 88mm
BPC-3112
Arestech
Intel® Core™ i5-1235U
N/A
6/1/4/2
HDMI
-20°C ~ 60°C
1x Full-Size Mini-PCIe, 1 x M.2 E-Key 2230, 1 x Micro-SIM Holder
238mm x 155mm x 55mm
BPC-3064
Arestech
Intel® Celeron® J6412
N/A
6/1/4/2
HDMI
-20°C ~ 60°C
1x Full-Size Mini-PCIe, 1 x Nano-SIM Holder
238mm x 155mm x 55mm
MERA-2100 Series
Brand
Arestech
CPU
Intel® Celeron® Processor J1900
Chipset
N/A
USB/SATA/COM/LAN
5/3/2/2
Display
HDMI/VGA/DVI/DP
Temp
-40°C ~ 70°C
Expansion
1x Full-size Mini-PCIe Socket (mux with mSATA) and 1 x Full-size Mini-PCIe
Dimension
168mm x 47mm x 135mm
規格書 / 查詢
MEVA-2012E/P
Brand
Arestech
CPU
Intel® Celeron® Processor J1900
Chipset
N/A
USB/SATA/COM/LAN
5/2/6/2
Display
HDMI/VGA/DP/DVI-I
Temp
-40°C ~ 70°C
Expansion
1x Full-size Mini-PCIe Socket, 1x Full-size Mini-PCIe, 2x SIM Holder, 4x Antenna Hole, 2x PCIe X4 Slots, 2x PIC Slots
Dimension
127mm x 168mm x 216 mm
規格書 / 查詢
MERA-2000 Series
Brand
Arestech
CPU
Intel® Celeron® Processor J1900
Chipset
N/A
USB/SATA/COM/LAN
5/2/2/2
Display
HDMI/VGA/DVI/DP
Temp
-40°C ~ 70°C
Expansion
1x Full-size Mini-PCIe Socket (mux with mSATA) and 1 x Full-size Mini-PCIe
Dimension
168mm x 47mm x 135mm
規格書 / 查詢
CB-2200/2250
Brand
Arestech
CPU
Intel® Alder Lake-N Processor N97 / Intel® Alder Lake Core™ i3-N305
Chipset
SoC
USB/SATA/COM/LAN
5/1/2/2
Display
DP
Temp
-40°C ~ 70°C
Expansion
1 x Full-Size Mini-PCIe, 1 x M.2 B-Key, 2 x SIM Holders
Dimension
168 x 135 x 47mm
規格書 / 查詢
FLEX-BX210-Q470
Brand
IEI
CPU
10/11 th Gen Intel® Core™ CPU 35/65W
Chipset
Q470/Q470E
USB/SATA/COM/LAN
6/4/2/3
Display
HDMI/DP
Temp
-10°C ~ 50°C
Expansion
1 x M.2 B-Key 3042/52 socket (with SIM card slot, supporting 5G/LTE; supports PCIe 3.0 x1 & USB 3.2 Gen 1) 1 x M.2 M-Key 2280 socket (supports PCle 3.0 x4) 1 x M.2 A-Key 2230 (supports PCIe 3.0 x1 & USB 2.0)
Dimension
357mm x 230mm x 88mm
規格書 / 查詢
HTB-150-N6210
Brand
IEI
CPU
Intel® Celeron® Processor N6210
Chipset
N/A
USB/SATA/COM/LAN
4/0/1/2
Display
HDMI
Temp
0°C – 40°C
Expansion
1 x M.2 2230 A key slot, 1 x M.2 2280 M key slot
Dimension
137 mm x 102.8 mm x 36 mm
規格書 / 查詢
mBOX603
Brand
Axiomtek
CPU
13th/12th Gen Intel® Core™ i9/i7/i5/i3
Chipset
R680E
USB/SATA/COM/LAN
4/2/2/2
Display
HDMI/DisplayPort++
Temp
0°C ~ 40°C
Expansion
2 x Full-size PCIe, 1 x M.2 Key E 2230, 1 x M.2 Key B 3052/3042
Dimension
310mm x 332mm x 145mm
規格書 / 查詢
SB-5000
Brand
Arestech
CPU
13th/12th Gen Intel® Core™/Pentium®/Celeron® 35W LGA 1700
Chipset
Intel® R680E
USB/SATA/COM/LAN
9/2/6/6
Display
HDMI/VGA/DP
Temp
-40°C ~ 70°C
Expansion
1x Full-Size Mini-PCIe, 1 x M.2 B-Key 2242/3042/3052, 1 x M.2 E-Key 2230, 2 x Mini-SIM Holder
Dimension
240mm x 200mm x 88mm
規格書 / 查詢
BPC-3112
Brand
Arestech
CPU
Intel® Core™ i5-1235U
Chipset
N/A
USB/SATA/COM/LAN
6/1/4/2
Display
HDMI
Temp
-20°C ~ 60°C
Expansion
1x Full-Size Mini-PCIe, 1 x M.2 E-Key 2230, 1 x Micro-SIM Holder
Dimension
238mm x 155mm x 55mm
規格書 / 查詢
BPC-3064
Brand
Arestech
CPU
Intel® Celeron® J6412
Chipset
N/A
USB/SATA/COM/LAN
6/1/4/2
Display
HDMI
Temp
-20°C ~ 60°C
Expansion
1x Full-Size Mini-PCIe, 1 x Nano-SIM Holder
Dimension
238mm x 155mm x 55mm
規格書 / 查詢
